Solaris

React components for rendering the solar system with physically styled shader effects.

• Fourteen celestial scenes, from textured rocky bodies to procedural atmospheres
• Responsive composition, pointer lean, rotation, and directional lighting controls
• Per-component entry points so applications only import the effects they use
• Automatic offscreen pausing, WebGL context recovery, and reduced-motion support

Install

pnpm add @cuvii/solaris

Solaris requires React and React DOM 19.2 or newer.

Quick start

Each component is a client component and renders into a WebGL2 canvas. Import it from its own entry point for the smallest bundle:

'use client'

import { Moon } from '@cuvii/solaris/moon'

export function MoonPreview() {
  return (
    <Moon
      textures={{
        albedo: '/textures/moon-albedo.webp',
        normalHeight: '/textures/moon-normal-height.webp',
      }}
      spin={0.5}
      sunAzimuth={35}
      sunElevation={15}
      style={{ height: 400, width: 400 }}
    />
  )
}

Texture files are not included in the package. Host them in your application or on a CORS-enabled remote origin and pass their URLs to the component.

API

Components

Component	Import	Required textures	Capabilities
Earth	@cuvii/solaris/earth	cloud, day, material, night, normal, roughness	Canvas, pose, lighting, lifecycle
Jupiter	@cuvii/solaris/jupiter	albedo	Canvas, pose, lighting, lifecycle
Mars	@cuvii/solaris/mars	albedo, normalHeight	Canvas, pose, lighting, lifecycle
Mercury	@cuvii/solaris/mercury	albedo, normalHeight	Canvas, pose, lighting, lifecycle
Moon	@cuvii/solaris/moon	albedo, normalHeight	Canvas, pose, lighting, lifecycle
LunarEclipse	@cuvii/solaris/moon	albedo, normalHeight	Canvas, yaw/tilt, eclipse direction, lifecycle
Neptune	@cuvii/solaris/neptune	None (procedural)	Canvas, pose, lighting, lifecycle
Pluto	@cuvii/solaris/pluto	albedo, normalHeight	Canvas, pose, lighting, lifecycle
Saturn	@cuvii/solaris/saturn	atmosphere, rings	Canvas, pose, lighting, lifecycle
Sky	@cuvii/solaris/sky	None (procedural)	Canvas
Sun	@cuvii/solaris/sun	observation	Canvas, yaw/spin, lifecycle
Titan	@cuvii/solaris/titan	None (procedural)	Canvas, pose, lighting, lifecycle
Uranus	@cuvii/solaris/uranus	None (procedural)	Canvas, yaw/spin, pole controls, lighting, lifecycle
Venus	@cuvii/solaris/venus	cloudStructure	Canvas, pose, lighting, lifecycle

The package root also exports every component, but the per-component entry points make the bundle boundary explicit. Each entry point exports its component, matching *Props type, texture type when applicable, and the shared types it uses.

Every visual control is typed and documented with its unit, useful range, and default in JSDoc. Use the exported props type or editor autocomplete for the full set of body-specific atmosphere, surface, ring, and exposure controls.

Canvas and layout

These fields come from OrbCanvasProps and apply to every component unless noted.

Prop	Type	Default	Description
className	string	—	Class name for the outermost element
style	CSSProperties	—	Inline styles for the outermost element
composition	OrbComposition	—	Size and vertical position of the body inside the canvas
viewport	OrbViewport	—	Extra canvas bleed around composition
lean	boolean	true	Follow the pointer with a subtle parallax lean; unavailable on Sky
paused	boolean	false	Stop the render loop
onError	(error: Error) => void	—	Receive renderer or source failures

OrbComposition contains required width and height CSS values plus an optional bottom. It is horizontally centred. Without it, the body fills the shorter side of the canvas.

OrbViewport accepts CSS top, right, bottom, and left values and is only used with composition. Negative values grow the canvas so rings, glow, and atmosphere are not clipped:

<Saturn
  composition={{ bottom: 40, height: 480, width: 480 }}
  viewport={{ bottom: -120, left: -120, right: -120, top: -120 }}
  textures={textures}
/>

Pose and lighting

Prop	Unit	Description
yaw	degrees	Rotation about the polar axis
tilt	degrees	Axial tilt towards the viewer
spin	degrees per second	Continuous rotation added to yaw
sunAzimuth	degrees	Light around the vertical axis; 0 is front and ±90 is from either side
sunElevation	degrees	Light height above the equatorial plane; negative values light from below

Most bodies support all five fields. The exceptions are:

• LunarEclipse has no spin; its sun angles move Earth's shadow across the Moon.
• Neptune uses tilt to rotate its weather map without changing lighting geometry.
• Sun has yaw and spin, but no tilt or lighting controls.
• Uranus has yaw and spin; use poleAzimuth and poleElevation for its pole.
• Sky has no pose or lighting group; its own sunElevation controls the observed Sun.

Source lifecycle

Textured and generated-source components accept SourceLifecycleProps:

Prop	Type	Description
onStatusChange	(status: 'loading' | 'ready' | 'error') => void	Receive every source state transition
onReady	() => void	Run when images are decoded or generated data is available
onError	(error: Error) => void	Receive texture, shader, framebuffer, or invalid-source failures

ready means source data is available; GPU upload follows on the next frame. Renderer errors leave the canvas blank and do not escape into the React tree. Sky is fully procedural in one render pass and does not expose source lifecycle callbacks.

Textures and preloading

Texture objects are keyed by URL values, so inline objects are safe and do not rebuild the renderer while their strings remain unchanged. Remote texture servers must allow anonymous cross-origin image requests.

Import preloadTextureImages from the package root to warm the shared image cache:

import { preloadTextureImages } from '@cuvii/solaris'

await preloadTextureImages(['/textures/moon-albedo.webp', '/textures/moon-normal-height.webp'])

Earth atmosphere model

Earth uses defaultEarthModel unless you provide a different scattering model. The preset and its types are exported from the Earth entry point:

import {
  Earth,
  defaultEarthModel,
  type AtmosphericOrbModel,
  type EarthProps,
} from '@cuvii/solaris/earth'

const model: AtmosphericOrbModel = {
  ...defaultEarthModel,
  sunIntensity: 20,
}

export function CustomEarth(props: EarthProps) {
  return <Earth {...props} model={model} />
}

Runtime behavior

• WebGL2 is required. Without it, the canvas stays blank and no error is thrown into React.
• Rendering pauses while the canvas is outside the viewport.
• Rendering pauses on WebGL context loss and resumes after the context is restored.
• Under prefers-reduced-motion, time is frozen, pointer lean is disabled, and the component redraws only when its props or size change.

Development

src/ contains the publishable package. website/ contains the Next.js showcase and its hosted demo textures.

pnpm install
pnpm exec playwright install chromium # once, for browser tests
pnpm dev

Run the project checks with:

pnpm check
pnpm build
pnpm test
pnpm build:website

Build before testing: src/dist.test.ts inspects the emitted bundles and is skipped when dist/ is missing.

Credits

Texture provenance for the showcase is recorded in website/public/textures/v1/CREDITS.md.

See also

• Cobe — Shu Ding
• Spherium — Javier Crocco
• GPS 01 — Dmytro Kondakov
• On Rendering the Sky, Sunsets and Planets — Maxime Heckel
