Camera based skew calibration for Klipper

Camera-based XY skew calibration for Klipper using a toolhead-mounted camera and a ChArUco board. Fast, repeatable, and automated.

▶️ Video walkthrough

Please watch this Video where I explain the project:

⚠️ Disclaimer

Early version. Verify results and keep hands clear while the printer moves. Use at your own risk.

✨ Features

• Automated Klipper XY skew calibration with a camera and ChArUco board
• Works with Moonraker and HTTP/MJPEG cameras (e.g. crowsnest)
• Stores camera intrinsics to K.npy and dist.npy for reuse
• Prints ready-to-use Klipper command: SET_SKEW XY=...
• Reports observed axis travel for a commanded 100 mm move and if a significant scale error is detected, prints suggested rotation_distance correction factors for X/Y

🧠 How it works

1. Board: Print or use the provided PDFs and tape the ChArUco board flat on the bed (100% scale, no fit-to-page).
2. Guided capture: The tool moves the toolhead and captures images at multiple XY offsets and Z heights to diversify perspective for robust calibration.
3. Intrinsics: OpenCV (CharucoDetector) detects corners across images and calibrates the camera, saving K.npy and dist.npy.
4. Skew solve: With the calibrated camera, the tool collects poses across the bed, estimates the camera–nozzle offset and an affine map from commanded XY to observed board XY, then emits SET_SKEW parameters for Klipper. Additionally, it reports observed axis travel for a 100 mm and when the error is significant, prints rotation_distance correction hints for X and Y.

📦 Requirements

• Python 3.8+ (Linux recommended)
• Klipper + Moonraker reachable from your host
• A camera reachable via HTTP snapshot/MJPEG (typical crowsnest URL) or a local index supported by OpenCV
• OpenCV: opencv-python>=4.10

Optional (for PDF generation only): Pillow, img2pdf, pikepdf

🛠️ Install

• Create/activate a venv if desired, then install:

pip install -r requirements.txt

🚀 Quick start

1) Print the ChArUco board (recommended)

• Open and print either charuco_A4_5mm.pdf or charuco_Letter_5mm.pdf depending on your paper size.
• Print at 100% scale (Actual Size). Do not use "Fit to page". Tape the sheet flat and square to the bed.
• You do NOT need to run generate-board unless you want to regenerate these PDFs yourself.

Optional (regenerate PDFs yourself — requires extras):

skew_correction.py generate-board

Experimental: Bambu Lab Vision Encoder board

• You can also try using the original Bambu Lab Vision Encoder board (untested).
• It uses a custom 7x7 ArUco dictionary and has small 2.5 mm fields on a 132×128 grid.
• This may require a higher-resolution camera and/or the ability to focus very close.
• Usage:

# One-time intrinsics (experimental mode):
skew_correction.py calibrate-camera "camera_calibration_imgs/*.jpg" --vision-encoder

# Run skew (experimental mode):
skew_correction.py skew --z 40 --vision-encoder

2) Capture images for camera intrinsics (one-time setup)

This moves the toolhead through a guided pattern to capture multiple views and saves images to camera_calibration_imgs/. Do this once per camera setup, and only repeat if you change focus, resolution, lens, or the camera mount. Adjust --camera-id if your camera URL or index differs.

skew_correction.py capture-calibration-images \
  --camera-id http://klipper.local/webcam/?action=snapshot

3) Calibrate intrinsics and save K.npy / dist.npy (one-time setup)

This reads the captured images, detects ChArUco corners, and computes camera intrinsics. It writes K.npy and dist.npy for reuse. You typically do this once; future skew runs will reuse these files.

skew_correction.py calibrate-camera "camera_calibration_imgs/*.jpg"

4) Run skew calibration and print the Klipper command (repeat as needed)

This captures poses over the bed, estimates camera–nozzle offset and XY skew, and prints a ready-to-use Klipper command like SET_SKEW XY=.... Run this whenever you want to re-check or update skew; it reuses K.npy and dist.npy.

skew_correction.py skew --z 40

Defaults can be overridden with flags or env vars (see below).

When skew completes, the tool also:

• Reports the observed travel for a 100 mm command along X and Y (assuming the board is printed at 100% scale)
• If the axis scale error is significant, prints a hint with suggested correction factors:
  • Klipper: new rotation_distance = old rotation_distance × factor (per-axis)

Note on one-time vs recurring steps:

• Steps 2–3 (intrinsics capture and calibration) are one-time per camera configuration.
• Step 4 (skew) is what you run each time you want updated skew values.

🔧 Command reference

• Regenerate board PDFs (A4, Letter) alteratively use Bambu Vision Encoder board (experimental):

  • skew_correction.py generate-board
  • Note: Not required for normal use; the repository already includes charuco_A4_5mm.pdf and charuco_Letter_5mm.pdf for printing.

• Guided capture for intrinsics:

  • skew_correction.py capture-calibration-images [--camera-id URL] [--z 40.0] [--margin 10.0] [--dx 20.0] [--dy 20.0] [--moonraker-url URL]

• Calibrate camera intrinsics from images:

  • skew_correction.py calibrate-camera "camera_calibration_imgs/*.jpg"
  • Add --vision-encoder to use the experimental Bambu board.

• Skew calibration (prints SET_SKEW command):

  • skew_correction.py skew [--camera-id URL] [--z 40.0] [--margin 25.0] [--moonraker-url URL]
  • Add --vision-encoder to use the experimental Bambu board.

Environment variables (defaults):

• PRINTER_URL = http://klipper.local
• Camera URL default = http://klipper.local/webcam/?action=snapshot

Running on the printer (localhost):

• If you run this directly on the printer host, set the URL(s) to localhost, e.g.: export PRINTER_URL=http://localhost or
  • --moonraker-url http://localhost:7125 and
  • --camera-id http://localhost/webcam/?action=snapshot (adjust path to your setup)

✅ Tips for best results

• Print the board at 100% scale; tape it flat and square to the bed
• Ensure good, even lighting; avoid glare and motion blur (the tool dwells before capture)
• Capture enough diverse views for intrinsics; the guided flow suggests small tilts between phases
• Reuse your K.npy/dist.npy for future runs unless you change camera focus, mount, or resolution

📂 Files produced

• K.npy, dist.npy: camera intrinsics saved in the project directory
• camera_calibration_imgs/: captured images for intrinsics
